Model: DB - 1000
Especially robust steel welded construction, with a Thrust Ball Bearing 017 and Tapered roller bearing 30204 in swivel head, fited with Grease Nipple. Dust and splash proof Nylon washer Solid welded central king pin bolted and manually secured.
- Sizes available : 4" to 8"
- Capacity : 150 to 1000 kgs.
- Technical data:
Model: ULTRA-800
Pressed Steel Construction and Steel Welded with Twin Ball race in Swivel Head, Dust proof Nylon Seals, Fitted with Grease Nipple, Heavy Central King Pin bolted and manually secured.
- Sizes Available : 4" to 8"
- Capacity : 100 to 600 Kgs
- Technical data:
Model: MAC - 600
Pressed steel construction and steel welded with twin ball race in swivel head, dust proof nylon seals, heavy central king pin bolted and manually secured.
- Sizes : 4" to 8"
- Capacity : 100 to 600 kgs.
- Technical data:
Model: SFX - 800
Forged Steel unbreakable body, with Steel Ring assembly, Self Lock balls system, No king Pin,Single Balls race, Fitted with Grease nipple, Dust Proof Nylon Washer. Also available Wheel Lock and Swivel Lock.
- Sizes : 4" To 16"
- Capacity : 100 To 800 Kgs.
- Technical data:
Model: FOX -100
Pressed Steel Construction and Steel Welded with Single Ball race in Swivel Head, Dust proof Nylon Washer, Central King Pin bolted and manually secured.
- Sizes : 3" to 8"
- Capacity : : 40 to 100 Kgs
- Technical data:
Model: DEL - 400
Pressed Steel Construction ans Steel Welded with Twin Ball race in Swivel Head, Dust Proof Nylon Seals, Heavy Central King Pin bolted and manually secured.
- Sizes : 3" to 8"
- Capacity : 75 to 400 Kgs.
- Technical data:
Model: DBS - 200
Steel welded construction, with twin ball race in the swivel head, Heavy central King pin bolted and manually secured.
- Sizes : 3" to 8"
- Capacity : 50 To 200Kgs.
- Technical data:
Model: DBL - 150
Pressed steel construction and steel welded with double ball race in swivel head, dust proof nylon washer, central king pin bolted and manually secured.
- Sizes : 4" to 8"
- Capacity : 40 to 150 kgs
- Technical data:
Model: MSD - 200
Steel welded construction, with twin ball race in the swivel head, Heavy central King pin bolted and manually secured.
- Sizes : 3 To 8
- Capacity : 50 To 200Kgs.
- Technical data:
